Product Details:

Place of Origin: Fujian, China
Brand Name: Genilight
Model Number: SC 800x800-P10(Two sides)

Payment & Shipping Terms:

Minimum Order Quantity: 5 pieces
Price: $1,600.00/pieces 5-49 pieces
Packaging Details: carton box,wooden box,or packing as your request<br>LED cross medical pharmacy display business commercial sign
Payment Terms: T/T, MoneyGram, PayPal, Western Union
Supply Ability: 100000 Piece/Pieces per Month LED cross medical pharmacy display business commercial sign
Get Best Price Contact Now

Detail Information

Application: Outdoor Color: RGB, Red,Blue,Green,Yellow,White Etc..
Supplier Type: Original Manufacturer, ODM, OEM Use: Advertising Publish, Retail Store, Medical Treatment
Screen Dimension: 520*520mm,800*800mm, 1000*1000mm, 1024*1024mm Etc.. Tube Chip Color: Single Color, Two Color Or Full Color
Pixels: 10mm, 16mm, 20mm,25mm IP Grade: IP65
Operation: Easy For Installation And Operation Display: Message, Time, Temperature, Text, Video
Port: XIAMEN,SHANGHAI,SHENZHEN

Product Description

Product Description

Outdoor WaterproofLed Pharmacy display sign

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 0
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 1
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 2

Specifications

1. LED chip size

red:9mil,green/blue/amber/white:12mil

2. View Angle

H:120°(+60/-60),V:60°(+30/-30)

3. Viewing Distance

≥20m

4. Input voltage (AC)

110V~240V

5. Input power frequency (Hz)

50HZ~60HZ

6. Control Mode

Asynchronous

7. Drive Mode

1/4 scan constant current (1200×1200 is static scan)

8. Communication Mode

RS232,RF Wireless, WIFI(Optional)---The default configuration(RF Wireless)

9. Control distance

RS232:<100m,RF Wireless:<800m

10. Display content

Animation/Graphics/Word/Time/Temperature

11. Languages

English, French, Spanish ,Greek,Russian and Italian

12. Operating system

Windows (2000/XP/Vista/Win7)

13. Frame Material

Steel(cold rolled iron) frame.500*500,800*800,1000*1000 can do aluminum frame

14. Working Temperature(°C)

-45~+65(for working)

15. Working Humidity

10%~95%RH

16. Life span

100,000 hours

17.Certificate

CE-EMC,CE-LVD,ROHS


520*520mm led cross sign(two side)

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 3



P10-SC-520*520 (single color)

1. Pixel Pitch:10mm
2. Pixel configuration: one led (red/green/blue)
3. Display color: pure green,pure red,green with two lines blue fringe,red with two lines green fringe…
4. Display Pixels:2560 dots(for two sides, one side is 1280)
5. Brightness: 6000CD
6. IP grade:IP65
7. MAX Power Consumption: 115W
8. Cabinet Size(mm): 890*540*100
9. Packing Meas.(mm): 950*610*240
10. Net Weight(kg):15
11. Gross Weight(kg):28

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 4



P10-TC-520*520 (two color)

1. Pixel Pitch:10mm
2. Pixel configuration: 1R1G or 1G1B or 1R1B
3. Display color: pure green,pure red,green with two lines blue fringe,red with two lines green fringe…
4. Display Pixels:2560 dots(for two sides, one side is 1280)
5. Brightness: 6000CD
6. IP grade:IP65
7. MAX Power Consumption: 200W
8. Cabinet Size(mm): 890*540*100
9. Packing Meas.(mm): 950*610*240
10. Net Weight(kg):15
11. Gross Weight(kg):28

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 5



P10-FC-520*520 (full color)

1. Pixel Pitch:10mm
2. Pixel configuration: 1R1G1B
3. Display color: pure green,pure red,green with two lines blue fringe,red with two lines green fringe…
4. Display Pixels:2560 dots(for two sides, one side is 1280)
5. Brightness: 6000CD
6. IP grade:IP65
7. MAX Power Consumption:300W
8. Cabinet Size(mm): 890*540*100
9. Packing Meas.(mm): 950*610*240
10. Net Weight(kg):15
11. Gross Weight(kg):28

800*800mm led cross sign(two side)

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 6

P16-SC-800*800 (single color)
1. Pixel Pitch:16mm
2. Pixel configuration: one led (red/green/blue)
3. Display color: pure green,pure red,green with two lines blue fringe,red with two lines green fringe…
4. Display Pixels:2560 dots(for two sides, one side is 1280)
5. Brightness: 6000CD
6. IP grade:IP65

7. MAX Power Consumption: 145W
8. Cabinet Size(mm): 1176×820×100
9. Packing Meas.(mm): 1250×890×240
10. Net Weight(kg):26
11. Gross Weight(kg):43

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 7

P16-TC-800*800(two color)
1. Pixel Pitch: 16mm
2. Pixel configuration: three leds (2R1G/2R1B/1B1G)
3. Display color: red,green,yellow or green,blue,cyan
4. Display Pixels: 2560 dots(for two sides, one side is 1280)
5. Brightness: 6500CD
6. IP grade: IP65
7. MAX Power Consumption: 200W
8. Cabinet Size(mm): 1176×820×100
9. Packing Meas.(mm): 1250×890×240
10. Net Weight(kg): 27
11. Gross Weight (kg): 43

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 8

P16-TC-800*800(full color)
1. Pixel Pitch: 16mm
2. Pixel configuration: three leds (2R1G/2R1B/1B1G)
3. Display color: red,green,yellow or green,blue,cyan
4. Display Pixels: 2560 dots(for two sides, one side is 1280)
5. Brightness: 6500CD
6. IP grade: IP65
7. MAX Power Consumption: 200W
8. Cabinet Size(mm): 1176×820×100
9. Packing Meas.(mm): 1250×890×240
10. Net Weight(kg): 27
11. Gross Weight (kg): 43

1000*1000mm led cross sign(two side)

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 9



P20-SC-1000*1000

1. Pixel Pitch: 20mm
2. Pixel configuration: one led (red/green/blue)
3. Display color: pure green,pure red,green with two lines blue fringe,red with two lines green fringe…
4. Display Pixels: 2560 dots (for two sides, one side is 1280)
5. Brightness: 5500CD
6. IP grade: IP65
7. MAX Power Consumption: 145W
8. Cabinet Size(mm): 1368×1010×100
9. Packing Meas.(mm): 1440×1070×240
10. Net Weight(kg): 38
11. Gross Weight(kg): 60

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 10



P20-TC-1000*1000

1. Pixel Pitch: 20mm
2. Pixel configuration: three leds (2R1G/2R1B/1B1G)
3. Display color: red,green,yellow or green,blue,cyan
4. Display Pixels: 2560 dots(for two sides, one side is 1280)
5. Brightness: 6000CD
6. IP grade: IP65
7. MAX Power Consumption: 200W
8. Cabinet Size(mm): 1368×1010×100
9. Packing Meas.(mm): 1440×1070×240
10. Net Weight(kg): 38
11. Gross Weight (kg): 60

ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 8



P20-FC-1000*1000

1. Pixel Pitch: 20mm
2. Pixel configuration: 1R1G1B
3. Display color: red,green,yellow or green,blue,cyan
4. Display Pixels: 2560 dots(for two sides, one side is 1280)
5. Brightness: 6000CD
6. IP grade: IP65
7. MAX Power Consumption: 200W
8. Cabinet Size(mm): 1368×1010×100
9. Packing Meas.(mm): 1440×1070×240
10. Net Weight(kg): 38
11. Gross Weight (kg): 60

Detailed Images
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 12
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 13
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 14
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 15
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 16
ODM Full Color LED Cross Pharmacy Sign with WIFI Control and 1G Pixel Configuration 17
Packing & Delivery

Packaging Details: carton box, wooden box or as your request.
Delivery Time: 15days, please check with us
